HIKVISION DS-9616NI-I8 User Manual

Network Video Recorder User Manual
28
1.2 IR Remote Control Operations
The device may also be controlled with the included IR remote control, shown in Figure 1-7.
In the Playback mode, the Up and Down
button is used to speed up and slow down
recorded video. The Left and Right button will
select the next and previous video files.
In live view mode, these buttons can be used
to cycle through channels.
In PTZ control mode, it can control the
movement of the PTZ camera.
ENTER
Use to confirm selection in any of the menu
modes
It can also be used to check checkbox fields.
In Playback mode, it can be used to play or
pause the video.
In single-frame Playback mode, pressing the
button will advance the video by a single
frame.
In Auto-switch mode, it can be used to stop
/start auto switch.
8
JOG SHUTTLE Control
Move the active selection in a menu. It will
move the selection up and down.
In Live View mode, it can be used to cycle
through different channels.
In the Playback mode: For
DS-9600NI-ST/RT/XT series, use ring to jump
30s forward/backward in video files. For
DS-8600NI-ST series, use outer ring to speed
up or slow down the record files and use inner
ring to jump 30s forward/backward in video
files.
In PTZ control mode, use to control the
movement of the PTZ camera.
9
POWER ON/OFF
Power on/off switch.

HIKVISION DS-9616NI-I8 Specifications

General

Sequence mode	Yes
Internal memory	4096 MB
Number of users	128 user(s)
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Internal memory type	DDR4
Throughput data rate	256 Mbit/s
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, MPEG4
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
RAID levels	0, 1, 5, 10
HDD capacity	8000 GB
HDD interface	Serial ATA
Maximum storage capacity	- TB
Number of HDDs installed	-
Number of HDDs supported	8
Total installed storage capacity	16000 GB
Product color	Black
Rack capacity	2U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	200 W

Weight and Dimensions

Depth	470 mm
Width	445 mm
Height	90 mm
