Network Video Recorder User Manual
86
7.3.3 Picture
The picture refers to the live picture capture in continuous or event recording type. (Storage >
Capture Schedule > Advanced)
Picture Quality: set the picture quality to low, medium or high. The higher picture quality results
in more storage space requirement.
Interval: the interval of capturing live picture.
Capture Delay Time: the duration of capturing pictures.
7.3.4 ANR
ANR (Automatic Network Replenishment) function which enables the IP camera to save the
recording files in the local storage when the network is disconnected, and when the network is
resumed, it uploads the files to the device.
Enable the ANR (Automatic Network Replenishment) function via the web browser
(Configuration > Storage > Schedule Settings > Advanced).
7.3.5 Configure Advanced Recording Settings
Step 1 Go to Storage > Schedule Settings > Record Schedule/Capture Schedule.
Step 2 Check Enable to enable scheduled recording.
Step 3 Click Advanced to set the recording parameters.
Figure 7-8 Advanced Record Settings
Record Audio: Check the checkbox to enable or disable audio recording.
Pre-record: The time you set to record before the scheduled time or event. For example, when
an alarm triggers the recording at 10:00, and if you set the pre-record time as 5 seconds, the
camera records at 9:59:55.

Table of Contents

Other manuals for HIKVISION DS-9616NI-I8

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HIKVISION DS-9616NI-I8 and is the answer not in the manual?

HIKVISION DS-9616NI-I8 Specifications

General IconGeneral
Sequence modeYes
Internal memory4096 MB
Number of users128 user(s)
Maximum resolution3840 x 2160 pixels
Alarm input channels16
Internal memory typeDDR4
Throughput data rate256 Mbit/s
Video input channels16 channels
Alarm output channels4
Supported resolutions3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supportedH.264, H.264+, H.265, MPEG4
Analog signal format systemNTSC, PAL
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity1
RAID levels0, 1, 5, 10
HDD capacity8000 GB
HDD interfaceSerial ATA
Maximum storage capacity- TB
Number of HDDs installed-
Number of HDDs supported8
Total installed storage capacity16000 GB
Product colorBlack
Rack capacity2U
Operating temperature (T-T)-10 - 55 °C
Operating relative humidity (H-H)10 - 90 %
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Power consumption (max)200 W
Weight and Dimensions IconWeight and Dimensions
Depth470 mm
Width445 mm
Height90 mm
