Network Video Recorder User Manual
157
Chapter 15 Network Settings
15.1 Configure TCP/IP Settings
Purpose
TCP/IP settings must be properly configured before you can operate the device will operate over a
network.
15.1.1 Device with Dual Network Interface
Step 1 Go to System > Network > TCP/IP.
Figure 15-1 TCP/IP Settings
Step 2 Select Net-Fault Tolerance or Multi-Address Mode under Working Mode.
 Net-Fault Tolerance: The two NIC cards use the same IP address, and you can select the main NIC
to LAN1 or LAN2. In this way, in case of one NIC card failure, the device will automatically enable
the other standby NIC card so as to ensure the normal running of the system.
 Multi-Address Mode: The parameters of the two NIC cards can be configured independently. You
can select LAN1 or LAN2 under Select NIC for parameter settings. Select one NIC card as the
default route. When the system connects with the extranet, the data will be forwarded through
the default route.
Step 3 Configure other IP settings as needed.

HIKVISION DS-9616NI-I8 Specifications

General

Sequence mode	Yes
Internal memory	4096 MB
Number of users	128 user(s)
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Internal memory type	DDR4
Throughput data rate	256 Mbit/s
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, MPEG4
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
RAID levels	0, 1, 5, 10
HDD capacity	8000 GB
HDD interface	Serial ATA
Maximum storage capacity	- TB
Number of HDDs installed	-
Number of HDDs supported	8
Total installed storage capacity	16000 GB
Product color	Black
Rack capacity	2U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	200 W

Weight and Dimensions

Depth	470 mm
Width	445 mm
Height	90 mm
