HIKVISION DS-9616NI-I8 User Manual

Network Video Recorder User Manual
190
18.4 Import/Export Device Configuration Files
Purpose
The device configuration files can be exported to a local device for backup; and the configuration
files of one device can be imported to multiple devices if they are to be configured with the same
parameters.
Before You Start
Connect a storage device to your device. To import the configuration file, the storage device must
contain the file.
Step 1 Go to Maintenance >Import/Export.
Figure 18-7 Import/Export Config File
Step 2 Export or import the device configuration files.
 Click Export to export configuration files to the selected local backup device.
 To import a configuration file, select the file from the selected backup device and click the
Import.
After having finished importing configuration files, the device will reboot automatically.
18.5 Configure System Services
18.5.1 Control4 Protocol
The Control4 protocol enables you to search the Hikvision devices via SDDP, get the basic network
parameters, device information, or access some device operations.
Step 1 Go to Menu > Maintenance > System Service > More Settings > Control4.

HIKVISION DS-9616NI-I8 Specifications

General

Sequence mode	Yes
Internal memory	4096 MB
Number of users	128 user(s)
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Internal memory type	DDR4
Throughput data rate	256 Mbit/s
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, MPEG4
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
RAID levels	0, 1, 5, 10
HDD capacity	8000 GB
HDD interface	Serial ATA
Maximum storage capacity	- TB
Number of HDDs installed	-
Number of HDDs supported	8
Total installed storage capacity	16000 GB
Product color	Black
Rack capacity	2U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	200 W

Weight and Dimensions

Depth	470 mm
Width	445 mm
Height	90 mm
