HIKVISION DS-9616NI-I8 User Manual

Network Video Recorder User Manual
68
Step 3 Select a constant window-division layout or custom layout from the toolbar.
Step 4 Select a division window, and double-click on a camera in the list to link the camera to the
window.
You can enter the number in the text field to quickly search the camera from the list.
You can also click-and-drag the camera to the desired window on the Live View interface to set the
camera order.
Step 5 Click Apply.
Related Operations:
 Click to start Live View for all channels.
 Click to stop all Live View channels.
5.5 Configure Camera Auto-Switch
You can set the camera’s auto-switch to play in different display modes.
Step 1 Go to System > Live View > General.
Step 2 Set the video output interface, Live View mode and dwell time.
 Video Output Interface: Select the video output interface.
 Live View Mode: Select the display mode for Live View, e.g., 2*2, 1*5, etc.
 Dwell Time: The time in seconds to wait between switching of cameras when in auto-switch.
The range is from 5s to 300s.
Step 3 Go to View Settings to set the view layout.
Step 4 Click OK.
5.6 Configure Channel-Zero Encoding
Purpose
Enable the channel-zero encoding when you need to get a remote view of many channels in real
time from a web browser or CMS (Client Management System) software, in order to decrease the
bandwidth requirement without affecting the image quality.
Step 1 Go to System>Live View>General.

HIKVISION DS-9616NI-I8 Specifications

General

Sequence mode	Yes
Internal memory	4096 MB
Number of users	128 user(s)
Maximum resolution	3840 x 2160 pixels
Alarm input channels	16
Internal memory type	DDR4
Throughput data rate	256 Mbit/s
Video input channels	16 channels
Alarm output channels	4
Supported resolutions	3840 x 2160, 2560 x 1440, 1920 x 1080, 1600 x1200, 1280 x 1024, 1280 x 720, 1024 x 768
Video formats supported	H.264, H.264+, H.265, MPEG4
Analog signal format system	NTSC, PAL
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	1
RAID levels	0, 1, 5, 10
HDD capacity	8000 GB
HDD interface	Serial ATA
Maximum storage capacity	- TB
Number of HDDs installed	-
Number of HDDs supported	8
Total installed storage capacity	16000 GB
Product color	Black
Rack capacity	2U
Operating temperature (T-T)	-10 - 55 °C
Operating relative humidity (H-H)	10 - 90 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	200 W

Weight and Dimensions

Depth	470 mm
Width	445 mm
Height	90 mm
