HIKVISION DS-9616NI-I8 - Page 42

Network Video Recorder User Manual
41
1
USB Interface
Universal Serial Bus (USB 3.0) ports for additional devices
such as USB mouse and USB Hard Disk Drive (HDD).
2
LAN Network
Interface
1 10/100/1000 Mbps self-adaptive Ethernet interface
3
Audio In
RCA connector for audio input.
4
Audio Out
RCA connector for audio output.
5
VGA Interface
DB9 connector for VGA output. Display local video
output and menu.
6
CVBS Video
Output
RCA connector for video output.
7
RS-232 Serial
Interface
Connector for RS-232 devices.
8
eSATA Interface
Connects external SATA HDD, CD/DVD-RM.
9
SW Terminal
Switch
Up position is not terminated.
Down position is terminated with 120Ω resistance.
10
RS-485,
Keyboard
Controller
Connector for RS-485 devices. T+ and T- pins connect to
R+ and R- pins of PTZ receiver respectively.
11
ALARM IN
Connector for alarm input.
ALARM OUT
Connector for alarm output.
12
Network
Interfaces with
PoE function
(supported by
DS-8600NI-I8/P)
Network interfaces for the cameras and to provide
power over Ethernet.
13
Power Switch
Switch for turning on/off the device.
14
Power Supply
100V to 240V AC power supply.
15
Ground
Ground (needs to be connected when NVR starts up).
