HIKVISION DS-K1T981 Series User Manual

Figure 3-13 Install Mounng Template
2. R
emove the back cover plate, route the cables through the cable hole, and connect them to the
corresponding external devices' cables.
3. Install the back cover plate back, and install the device on the bracket with 1 supplied screw (SC-
KM3×6-T10-SUS).
Figure 3-14 Install Device
4. Aer
installaon, for the proper use of the device (outdoor use), sck the protecon lm (parts
of models supplied) on the screen.
DS-K1T981 Series Access Control Terminal User Manual
14

HIKVISION DS-K1T981 Series Specifications

General

Brand	HIKVISION
Model	DS-K1T981 Series
Category	Touch terminals
Language	English
