HIKVISION DS-K1T981 Series - Bracket Mounting

Figure 3-10 Drill Holes on Turnsle
2. If the
installaon angle needs to be 180° perpendicular to the body of the turnsle, the
following operaons are required.
1)
Take o the 3 screws shown in the following gure.
Figure 3-11 Take o Screws
2) Rotate the
xed part by 180°, and install the 3 screws back.
Figure 3-12 Rotate Fixed Part
3.4.2 Bracket Mounng
Steps
1. Ins
tall the mounng template on the bracket with 4 supplied screws (SC-K1M4×8-SUS).
