HIKVISION DS-K1T981 Series User Manual

Note
●
If c
onnects to an access controller, you should set the Wiegand direcon as Output to transmit
authencaon informaon to the access controller.
●
For details about Wiegand direcon sengs, see
Set Wiegand Parameters
.
●
Do not wire the device to the electric supply directly.
4.3 Wire Secure Door Control Unit
You can connect the terminal with the secure door control unit.
The wiring diagr
am is as follows.
Figure 4-3 Secure Door Control Unit Wiring
Note
The secure door control unit should connect to an external power supply separately. The suggested
e
xternal power supply is 12V, 0.5A.
4.4 Wire Fire Module
4.4.1 Wiring Diagram of Door Open When Powering O
Lock Type: Anode Lock,
Magnec Lock, and Electric Bolt (NO)
Security Type: Door Open When Powering O
Scenario: Installed in Fire Engine Access
DS-K1T981 Series Access Control Terminal User Manual
21
