37
Power Measurement (Power/Power Factor)
Measurement display 4 (calculation result)
(3-phase active power)
The measured value is cleared and returns to the initial connection display.
When the active power
is negative,
“
−
”
appears
beside it.
Long press
3-phase active power
Active power 2
Active power 3
Active power 1
Displays
alternately
11
10
• You can switch the information shown on the nal measurement display with the SHIFT key.
See "Switching the information shown on the measurement display" (p. 24)
• If the screen turns red: "Warning display" (p. 66)
To Next Page
