Hioki CM3286 - Page 49

43
Single-phase Energy Meter Comparison Function [Setting Wh]
1‑cycle mode
Mechanical meter
Once the disc has completed one revolution
Electronic meter
When the LED ashes once
Disc
Start integration
Stop integration
LED
Start integration
Stop integration
Fixed energy mode
e.g.: With the xed energy set to 0.1 kWh
0.1 kWh digit
Start integration
Stop integration
