79
Accuracy Table
Single-phase
active power/
Balanced
3-phase/4-wire
active power
(
P
/
P
(3P4W)
)
Range conguration (minimum resolution) Current range
6.000 A 60.00 A 600.0 A
Voltage range 600.0 V Single-
phase
3.600 kW
(0.001 kW)
36.00 kW
(0.01 kW)
360.0 kW
(0.1 kW)
3-Phase
4-Wire
10.80 kW
(0.01 kW)
108.0 kW
(0.1 kW)
1080 kW
(1 kW)
Accuracy (Power factor =1) Single-
phase
±2.0% rdg.
±7 dgt.
±1.7% rdg. ±5 dgt.
3-Phase
4-Wire
±2.0% rdg.
±3 dgt.
±1.7% rdg. ±2 dgt.
Single-phase
apparent power/
Balanced
3-phase/4-wire
apparent power
(
S
/
S
(3P4W)
)
Single-phase
reactive power/
Balanced
3-phase/4-wire
reactive power
(
Q
/
Q
(3P4W)
)
Accuracy ±1 dgt. relative to calculation from measured values
Range conguration For the above active power range conguration
,
the unit [W]
is replaced by [VA] for apparent power values. For reactive
power values
,
the unit [W] is replaced by [var].
