Accuracy Table
Range conguration when setting a CT ratio
CT ratio
1/1
(default value)
1/10 1/100 1/1000 Remarks
Current RMS
value
600.0 A 6000 A – –
CT ratio 1/1 Same accuracy
specications as 600.0 A.
60.00 A 600.0 A 6000 A –
CT ratio 1/1 Same accuracy
specications as 60.00 A.
6.000 A 60.00 A 600.0 A 6000 A
CT ratio 1/1 Same accuracy
specications as 6.000 A.
Current peak
value
1000 A 10.00 kA – –
CT ratio 1/1 Same accuracy
specications as 600.0 A.
180.0 A 1800 A 18.00 kA –
CT ratio 1/1 Same accuracy
specications as 60.00 A.
18.00 A 180.0 A 1800 A 18.00 kA
CT ratio 1/1 Same accuracy
specications as 6.000 A.
Single-phase
active power
360.0 kW 3600 kW – –
CT ratio 1/1 Same accuracy
specications as 360.0 kW.
36.00 kW 360.0 kW 3600 kW –
CT ratio 1/1 Same accuracy
specications as 36.00 kW.
3.600 kW 36.00 kW 360.0 kW 3600 kW
CT ratio 1/1 Same accuracy
specications as 3.600 kW.
