Appendix 1 About Recording Modes
A1
3
Appendix
The recording method depends on the selected recording mode. The recording
modes are as follows.
Measurements are recorded in internal memory at each recording interval.
Measurements are taken once per second, and instantaneous, maximum, minimum,
and a
verage values are saved to internal memory at each recording interval.
Data at the recording start time is not recorded (in the following case, data at 10:00:00
is not recorded).
Appendix
Appendix 1 About Recording Modes
Instantaneous Recording
Statistical Recording
Recording Interval
Instantaneous values are recorded
Recording Interval
(example: 1 min.)
10:01:00
Instantaneous values
are recorded
10:00:00
Recording Start
10:00:01 to 10:01:00
(measures once per second)
Maximum, minimum, and average values over
this time span are recorded.
Statistical recording cannot be selected when the recording interval is
set to one second.
To Next Page
