8.4 LR5091 Communication Adapter Specifications
84
Main Unit General Specifications
Accessories
8.4 LR5091 Communication Adapter Specifications
Functions
Converts between the logger's infrared signals and USB signals to sup-
port communications between the logger and a computer (USB port).
Compatible loggers
LR5001 Humidity Logger, LR5011 Temperature Logger, LR5031 Instru-
mentation Logger, LR5041 Voltage Logger (50 mV), LR5042 Voltage
L
ogger (5 V), LR5043 Voltage Logger (50 V), LR5051 Clamp Logger
Note: Communication with models LR5031 is supported by PC Utility
ve
rsion 1.05 and later.
LR5051 is supported by PC Utility version 1.01 and later.
Operating temperature
and humidity
Temperature: 0C to 40C (32.0F to 104.0F), Humidity: 80%RH or less
(non-condensating)
Storage temperature
and humidity
Temperature: -10C to 50C (14.0F to 122.0F), Humidity: 80%RH or
less (non-condensating)
Operating environment Indoors, pollution degree 2, up to 2000 m ASL
Power supply 5 VDC (USB bus-powered)
Maximum rated power 0.5 VA
Dimensions
Approx. 83W×61H×19D mm (3.27"W×2.40"H×0.75"D)
(without projections)
Mass Approx. 43 g (1.5 oz.) (without USB cable)
Applicable Standards
• Safety: EN61010
• EMC : EN61326
USB standard USB 2.0 compliant, Full Speed support
Connector Mini B series receptacle
Connectable device Computer
Communication speed 115,200bps
Communication method Half-duplex start/stop synchronous infrared serial communication
Communication speed 115,200bps
USB cable (1 m) ........................................................1
LR5000 Utility Program (CD) ....................................1
