1.3 Display Organization
14
The logger has two general display types: Measurement and Settings.
The (+) and (-) buttons switch the display type.
1.3 Display Organization
Measuring display
Channel 1 
measured value
Channel 2 
measured value
Channel 1
measured value
Recorded data count
Channel 2
measured value
Recorded data count
Channel 1 
maximum value
Channel 1 
minimum value
Channel 2 
maximum value
Channel 2 
minimum value
• For instantaneous
recording, the maxi-
mum and minimum
values are obtained
from all the data
measured at each
recording interval.
• For statistical
recording, the maxi-
mum and minimum
values are obtained
from all the data
measured every
second.
• The maximum and
minimum values are
not displayed when
the recorded data
count is 0.
