5.8 Converting Over-Threshold Data Values
70
Data values larger than the upper threshold and smaller than the lower threshold can
be converted to specified values.
Converted results are saved as new data items in the recording file.
1. Select the items and time span.
2. Set the upper and lower threshold values, and their corresponding conversion val-
ues.
3. Click the [Execute] butt
on.
(Conversion results are saved.)
Note: Click the [Finish] button to close the [OVER Data Revision] dialog box.
5.8 Converting Over-Threshold Data Values
Item and range settings
Select the items for conversion, and the time
span.
1
2
3
