4.6 Manually Importing (Saving) Recorded Data to a Computer, and Graph Display
55
3
4
Chapter 4 Measurement and Analysis
You can manually import (save) recorded data to a computer, and display it in a graph.
4.6 Manually Importing (Saving) Recorded Data
to a Computer, and Graph Display
2
Click to select.
The currently selected logger’s back-
ground is a different color.
3
3
Returns to the
main screen.
Click
Click
1
1
If the LR5000 Utility Program is not run-
ning on the computer, click the icon in the
task tray (notification area), and click
[Show Main Screen].
The main screen appears.
2
For the [Data Import] device, click the
[Logger] button.
The Data Import screen appears. If the logger
is not connected, you are prompted to con-
nect it. Connect the logger.
3
Select the logger in the list of devices, and
click the [Start Importing] or [Next]* but-
ton.
* If [Always specify folder and file before
importing]
on the Options screen is
enabled (p.78).
If you click the [Start Importing] button, data
importing starts ("Screen after importing data"
(p.57)).
If you click [Next], the Save Method screen
appears (p.56).
If multiple devices are listed, they can
be sorted in ascending order.
See: p.57
