8.2 Functional Specifications
82
8.2 Functional Specifications
Display type LCD
Display contents
Measured value, measurement channel, units (C,%), recording (REC),
endless recording (ENDLESS), statistical recording (STAT), recording
interval (INTVL), date and time (TIME), alarm (AL), battery status,
recorded data count (DATA), maximum value (MAX), minimum value
(MIN), auto power saving (APS)
Operation button Four ("SET", "REC/STOP", "+", "-")
Recording interval 1/2/5/10/15/20/30 sec., 1/2/5/10/15/20/30/60 min.
Recording modes
• Instantaneous recording: The instantaneous value is recorded at each
recording interval
• Statistical recording: Measurement
s are taken once per second, and
instantaneous, maximum, minimum, and average values are saved at
each recording interval (cannot be selected when the recording inter-
val is set to one second).
Recording capacity
• Instantaneous recording: 60,000 values/channel
• Statistical recording: 15,000 instantaneous, maximum, minimum, and
average values per channel
Recording start method
• Logger button operation
• Instant or scheduled time (set by computer/Data Collector)
Recording stop method
• Logger button operation (endless recording)
• Logger button operation (one-time recording)
• Scheduled time (endless recording)
• Scheduled time (one-time recording)
Scheduled time is set by computer/Data Collector
Retained recording
sessions
Two sessions (each from recording start to stop)
Alarm
Indicates when measured values are outside of the range defined by
upper and lower thresholds set from a computer or the Data Collector
Scaling
Scales and displays measured values according to settings made from a
computer or the Data Collector
Power save setting
The measurement data display turns off about 30 seconds after the last
button operation (cancel power save for continuous display)
Real-time clock Provided
