Hirschmann NetModule NB1601 - Mobile IP

If MIP is run as a home agent, you will have to set up a home address and network mask for the home
agent first. Then you will need to add the configuration for all mobile nodes which is made up of the
following settings:
NetModule Router Simulator
Hostname NB1600
Software Version 4.4.0.103
© 2004-2020, NetModule AG
Static Routes
Extended Routes
Multipath Routes
Multicast
IGMP Proxy
Static Routes
BGP
OSPF
Mobile IP
Administration
QoS
Administration
Classification
Mobile IP
Mobile IP can be used to move from one network to another while maintaining a permanent IP address and thus
avoiding that running IP sessions (including VPN tunnels) must be reconnected.
Administrative status:
mobile node
home agent
disabled
Primary home agent address:
194.29.27.205
Secondary home agent address: (optional)
Home address:
10.20.0.13
SPI:
103
Authentication type:
hmac-md5
Shared secret:
ASCII
••••••••
Life time:
1800
MTU:
1468
UDP encapsulation:
enabled disabled
Mobile network address: (optional)
Mobile network mask: (optional)
Apply
HOME INTERFACES ROUTING FIREWALL VPN SERVICES SYSTEM
LOGOUT
Figure 6.28.: Mobile IP
Parameter Konfiguration home agent
Home network address Home network address
Home network mask Home network mask
NB1601 102 User Manual for NRSW version 4.8.0.103
