4.4.7. GNSS
Feature Specification
Systems GPS/GLONASS/GALILEO/BEIDOU
Data stream JSON or NMEA
Tracking sensitivity up to -162 dBm
Supported antennas Active and passive
Table 4.11.: GNSS Specifications option G
The GNSS antenna port have the following specification:
Feature Specification
Max. allowed cable length 30 m
Antenna LNA gain 15-20 dB typ, 30 dB max.
Min. distance between collocated ra-
dio transmitter antennas
(Example: GNSS to MOB1)
20 cm
Connector type SMA
Table 4.12.: GNSS / GPS Antenna Port Specification
4.4.8. USB 2.0 Host Port
The USB 2.0 host port has the following specification:
Feature Specification
Speed Low, Full & Hi-Speed
Current max. 500 mA
Max. cable length 3 m
Cable shield mandatory
Connector type Type A
Table 4.13.: USB 2.0 Host Port Specification
NB1601 26 User Manual for NRSW version 4.8.0.103
