4.4.9. RJ45 Ethernet Connectors
Specification
The Ethernet port is specified as follows:
Feature Specification
Isolation 1500 VDC
Speed 10/100 Mbit/s
Mode Half- & Full-Duplex
Crossover Automatic MDI/MDI-X
Max. cable length 100 m
Cable type CAT5e or better
Cable shield mandatory
Connector type RJ45
Table 4.14.: Ethernet Port Specification
Pin Assignment
Pin Signal
1 TX+
2 TX−
3 RX+
4 -
5 -
6 RX−
7 -
8 -
Table 4.15.: Pin Assignments of RJ45 Ethernet Connector
Note: Pairs 4-5 and 7-8 have an internal 75 Ω termination.
