IP Settings
This page can be used to configure IP addressing for your LAN/WAN Ethernet interfaces.
Parameter LAN IP Settings
Mode Defines whether this interface is being used as LAN or WAN interface.
MTU The Maximum Transmission Unit for the interface, if provided it will
specify the largest size of a packet transmitted on the interface.
NB2800 NetModule Router
Hostname NB2800
Software Version 4.6.0.100
© 2004-2021, NetModule AG
WAN
Link Management
Supervision
Settings
Ethernet
Port Setup
VLAN Management
IP Settings
Mobile
Modems
SIMs
Interfaces
WLAN
Administration
Configuration
IP Settings
Bridges
USB
Serial
GNSS
IP Address Management
Network Interface Mode IP Address Mode IP Address Netmask
LAN1 LAN STATIC 192.168.1.1 255.255.255.0
LAN1-1 LAN STATIC 192.168.101.1 255.255.255.0
LAN1-2 LAN STATIC 192.168.102.1 255.255.255.0
LAN2 WAN DHCP - -
HOME INTERFACES ROUTING FIREWALL VPN SERVICES SYSTEM
LOGOUT
Figure 6.10.: LAN IP Configuration
NB1601 54 User Manual for NRSW version 4.8.0.103
