WLAN Administration
(Interfaces->WLAN->Administration)
NetModule Router Simulator
Hostname NB1600
Software Version 4.4.0.103
© 2004-2020, NetModule AG
WAN
Link Management
Supervision
Settings
Ethernet
Port Setup
VLAN Management
IP Settings
Mobile
Modems
SIMs
Interfaces
WLAN
Administration
Configuration
IP Settings
Bridges
USB
Serial
Digital I/O
GNSS
WLAN Management
Administrative status:
enabled
disabled
Operational mode:
client
access point
mesh point
dual modes
Regulatory domain:
HOME INTERFACES ROUTING FIREWALL VPN SERVICES SYSTEM
LOGOUT
Figure 6.64.: WLAN administration
Enable administration status and configure WLAN interface as follows:
Parameter Setting
Regulatory domain The country where the access point is used
Operation type To have optimal compatibility use 802.11n or 802.11ac if available
Radio band 2.4 GHz operation
Bandwidth 20Mhz
Channel 1 (2412 MHz)
NB1601 194 User Manual for NRSW version 4.8.0.103
