Attention:
When installing the antenna be sure to observe chapter 2
5.6. Installation of the Local Area Network
Four 10/100 Mbps Ethernet devices can be directly connected to the router, further devices can be
attached via an addtional Ethernet switch. Please ensure that the connector has been plugged in
properly and remains in a fixed state, you might otherwise experience sporadical link loss during op-
eration. The L/A (Link/Activity) LED will lit up as soon as the device has synced. If not, it might be
necessary to configure a different link setting as described in chapter 6.3.2 The S (Speed) LED is on
when the link speed is 100 Mbit/s. It’s off when the link speed is at 10 Mbit/s.
Attention:
Only a shielded Ethernet cable may be used.
5.7. Installation of the Power Supply
The router can be powered with an external source supplying between 12 VDC and 24 VDC. It is to be
used with a certified (CE or equivalent) power supply, which must have a limited and SELV circuit
output.Furthermore, power supply wires attached to V+ and V- inputs of the router must be able to
withstand up to 5A current without heating up significantly or damaging its isolation.
Attention: Only CE-compliant power supplies with a current-limited SELV output
voltage range may be used with the NetModule routers.
A Power Source Class 3 (PS3) power supply (with 100 W or more) shall only be
used under the condition that a cable strain relief on the power cable to the router is
applied. Such a cable strain relief ensures that the wires on the router screw terminal
connector are not disconnected (e.g. if under an error condition, the router would be
tangling on the cable). The cable strain relief must withstand a pulling force of 30 N (for
router weight up to 1 kg) applied to the cable of the router.
Une alimentation de classe 3 (PS3) (100 W ou plus) ne doit etre utilisee que si
le cable d alimentation du routeur est equipe d un dispositif anti-traction. A condition qu
une decharge de traction soit appliquee au cable d alimentation du routeur. Une telle
decharge de traction permet de s assurer que les fils du connecteur a vis du routeur ne
soient pas deconnectes (par exemple si, en cas d erreur, le routeur s emmale dans le
cable). La decharge de traction du cable doit resister a une force de traction de 30 N
(pour un routeur d un poids inferieur ou egal a 1 kg) appliquee au cable du routeur.
NB1601 36 User Manual for NRSW version 4.8.0.103
