4.4.12. Digital Output
The isolated digital output ports have the following specification:
Feature Specification
Number of outputs 1 on-board
1 optional with COM/IO shield (EXT 1)
Limiting continuous current 1 A
Maximum switching voltage 32 VDC
Maximum switching capacity 32 W
Isolation 1500 Vp (transients)
Table 4.18.: Isolated Digital Outputs Specification
For connector type and pin assignment check chapter 4.4.14.
4.4.13. Digital Input
The isolated digital input ports have the following specification:
Feature Specification
Number of inputs 1 on-board
1 optional with COM/IO shield (EXT 1)
Maximum input voltage 32 VDC
Minimum voltage for level 1
(set) 9 VDC
Maximum voltage for level 0
(not set) 3 VDC
Isolation 1500 Vp (transients)
Table 4.19.: Isolated Digital Inputs Specification
Note: A negative input voltage is not recognized.
For connector type and pin assignment check chapter 4.4.14.
NB1601 29 User Manual for NRSW version 4.8.0.103
