Antenna Port Type
Table 5.1.: Cellular port types
Attention:
When installing the antenna be sure to observe chapter 2
5.3. Installation of the WLAN Antennas
The following table shows how to connect the WLAN antennas. The number of attached antennas
can be configured in the software. If only one antenna is used, it must be attached to the main port.
However, for better diversity and thus better throughput and coverage, we highly recommend using
two antennas.
Antenna Port Type
WLAN 1 A3 Main
WLAN 1 A4 Auxiliary
WLAN 2 A6 Main
WLAN 2 A7 Auxiliary
Table 5.2.: WLAN antenna port types
Attention:
When installing the antenna be sure to observe chapter 2
5.4. Installation of the Bluetooth Antenna
The Bluetooth antenna must be mounted to the connector BT, A3. Only use antennas with cables
shorter than 3 meters.
5.5. Installation of the GNSS Antenna
The GNSS antenna must be mounted to the connector GNSS. Whether the antenna is an active or
passive GNSS antenna has to be configured in the software. We recommend active GNSS antennas
for highly accurate GNSS tracking.
NB1601 35 User Manual for NRSW version 4.8.0.103
