Feature Specification
Connector type SMA
Table 4.8.: Mobile Antenna Port Specification
4.4.5. Bluetooth Low Energy
The NB1601supports Bluetooth Low Energy.
4.4.6. WLAN
The variants of the NB1601support a IEEE 802.11a/b/g/n WLAN module.
Standard Frequencies Bandwidth Max. Data Rate
802.11a 5 GHz 20 MHz 54 Mbit/s
802.11b 2.4 GHz 20 MHz 11 Mbit/s
802.11g 2.4 GHz 20 MHz 54 Mbit/s
802.11n 2.4 GHz 20 MHz 144 Mbit/s
802.11n 5 GHz 40 MHz 150 Mbit/s
Table 4.9.: IEEE 802.11 Standards
Note: 802.11n supports 2x2 MIMO in 2.4 GHz and 1x1 in 5 GHz.
The WLAN antenna ports have the following specification:
Feature Specification
Max. allowed cable length 30 m
Max. allowed antenna gain
including cable attenuation
3.2dBi (2,4GHz) resp. 4.5dBi (5GHz)
1
Min. distance between collocated ra-
dio transmitter antennas
(Example: WLAN1 to MOB1)
20 cm
Min. distance between people and an-
tenna
40 cm
Connector type SMA
Table 4.10.: WLAN Antenna Port Specification
1
Note: WLAN antennas with a higher amplification may be used with the NetModule router "Enhanced-RF-Configuration"
software license and the antenna gain and cable attenuation that have been correctly configured by certified specialized
personnel.
NB1601 25 User Manual for NRSW version 4.8.0.103
