4.4.10. Power Supply (PWR)
NB1601 routers have a non-isolated power supply input. It has the following specifications:
Feature Specification
Power supply nominal voltages 12 VDC and 24 VDC
Voltage range 12 VDC to 24 VDC (−20% / +20%)
Avg. power consumption 7 W
Max. power consumption 10 W
Max. cable length 30 m
Cable shield not required
Table 4.16.: Power Specifications
For connector type and pin assignment check chapter 4.4.14.
4.4.11. Serial RS-232
The RS-232 port has the following specification (bold characters show the default configuration):
Feature Specification
Protocol 3-wire RS-232: GND, TXD, RXD
Baud rate 300, 1 200, 2 400, 4 800, 9 600, 19 200, 38 400,
57 600, 115 200
Data bits 7 bit, 8 bit
Parity none, odd, even
Stop bits 1, 2
Software flow control none, XON/XOFF
Hardware flow control none
Galvanic isolation to enclosure none
Max. cable length 10 m
Cable shield not required
Table 4.17.: RS-232 Port Specification
For connector type and pin assignment check chapter 4.4.14.
NB1601 28 User Manual for NRSW version 4.8.0.103
