Hirschmann RSP 20 User Manual

44
Installation RSP 20/25/30/35
Release 08 08/2014
EMC interference
immunity
Standard
applications
Substation
applications
Electrostatic discharge
EN 61000-4-2
IEEE C37.90.3
Contact discharge ± 4 kV ± 8 kV
EN 61000-4-2
IEEE C37.90.3
Air discharge ± 8 kV ± 15 kV
Electromagnetic field
EN 61000-4-3 80 MHz ... 3000 MHz 10 V/m 10 V/m
IEEE 1613 80 MHz ... 1000 MHz — 35 V/m
Fast transients (burst)
EN 61000-4-4
IEEE C37.90.1
AC/DC supply connection ± 2 kV ± 4 kV
EN 61000-4-4
IEEE C37.90.1
Data line ± 4 kV ± 4 kV
Voltage surges - DC supply connection
EN 61000-4-5 line/ground ± 2 kV ± 2 kV
IEEE 1613 line/ground — ± 5 kV
EN 61000-4-5 line/line ± 1 kV ± 1 kV
Voltage surges - AC supply connection
EN 61000-4-5 line/ground ± 2 kV ± 4 kV
IEEE 1613 line/ground — ± 5 kV
EN 61000-4-5 line/line ± 1 kV ± 2 kV
Voltage surges - data line
EN 61000-4-5 line/ground ± 1 kV ± 4 kV
Conducted disturbances
EN 61000-4-6 150 kHz ... 80 MHz 10 V 10 V
Damped oscillation - AC/DC supply connection
EN 61000-4-12
IEEE C37.90.1
line/ground — 2.5 kV
EN 61000-4-12
IEEE C37.90.1
line/line — 1 kV
Damped oscillation - data line
EN 61000-4-12
IEEE C37.90.1
line/ground — 2.5 kV
EN 61000-4-12 line/line — 1 kV
Pulse magnetic fields
EN 61000-4-9 — 300 A/m
