Hitachi 670 Series Application Guide

Name Type Description
CH4 STRING Remote communication channel 4
COMFAIL BOOLEAN Detected error in the differential communication
COMALM BOOLEAN Delayed alarm signal for communication failure
BLKDIFF BOOLEAN Link error, values are substituted, diff protection is blocked
ADDRERR BOOLEAN Incoming message from non-valid address
RED_ACT BOOLEAN Redundant channel active
CRCERROR BOOLEAN Identified error by CRC check in incoming message
TRDELERR BOOLEAN Transmission time is longer than permitted
SYNCERR BOOLEAN Error in echo synchronization
REMBLKDF BOOLEAN Remote terminal indicates diff protection is blocked
GPSERROR BOOLEAN Problem with GPS synchronization in remote or local end
NOCARR BOOLEAN No carrier is detected in the incoming message
NOMESS BOOLEAN No start and stop flags identified for the incoming message
LNGTHERR BOOLEAN Wrong length of the incoming message
YBIT BOOLEAN Detected error in remote end with incoming message
LOWLEVEL BOOLEAN Low signal level on the receive link
PID-6474-OUTPUTSIGNALS v2
Table 9: LDCMRecBinS2_2M Output signals
Name
Type Description
COMFAIL BOOLEAN Detected error in the differential communication
COMALM BOOLEAN Delayed alarm signal for communication failure
BLKDIFF BOOLEAN Link error, values are substituted, diff protection is blocked
ADDRERR BOOLEAN Incoming message from non-valid address
RED_ACT BOOLEAN Redundant channel active
CRCERROR BOOLEAN Identified error by CRC check in incoming message
TRDELERR BOOLEAN Transmission time is longer than permitted
SYNCERR BOOLEAN Error in echo synchronization
REMBLKDF BOOLEAN Remote terminal indicates diff protection is blocked
GPSERROR BOOLEAN Problem with GPS synchronization in remote or local end
NOCARR BOOLEAN No carrier is detected in the incoming message
NOMESS BOOLEAN No start and stop flags identified for the incoming message
LNGTHERR BOOLEAN Wrong length of the incoming message
YBIT BOOLEAN Detected error in remote end with incoming message
LOWLEVEL BOOLEAN Low signal level on the receive link
ADINV1 BOOLEAN Analog data invalid in remote end
ADINV2 BOOLEAN Analog data invalid in remote end
ADINV3 BOOLEAN Analog data invalid in remote end
ADINV4 BOOLEAN Analog data invalid in remote end
ADINV5 BOOLEAN Analog data invalid in remote end
ADINV6 BOOLEAN Analog data invalid in remote end
ADINV7 BOOLEAN Analog data invalid in remote end
Table continues on next page
Section 4 1MRK505382-UEN Rev. K
Analog and binary signal transfer for line differential protection
52 Communication set-up, 670/650 series
Application Guide
© 2017 - 2023 Hitachi Energy. All rights reserved
