• Remove cables that are no longer being used. Retaining them inside the server can restrict airflow. If you
intend to use the removed cables later, label and store them for future use.
Cabling diagrams
Observe the following:
• Before cabling components, see the cabling guidelines.
• Use the cable part number or search feature to find your diagram.
Drive backplanes
Component cabling Cable part number
8 SFF box 1 cabling P51545-001
P51546-001
P51549-001
Table Continued
