184 Cabling

Secondary riser

Cable part number

Color

From

P46034-001

Orange

Riser board

System board

Option kit: P56074-B21

Secondary riser

Cable part number

Color

From

P46034-001

Orange

Riser board

System board

Option kit: P56074-B21
