Hardware options installation
About this task
WARNING: To reduce the risk of personal injury, electric shock, or damage to the equipment, remove
the power cord to remove power from the server. The front panel Power On/Standby button does not
shut off system power. Portions of the power supply and some internal circuitry remain active until AC
power is removed.
CAUTION: To prevent improper cooling or thermal damage, do not operate the server unless all PCI
slots have either an expansion slot cover or an expansion board installed.
To install the component:
Procedure
1. Power down the server.
2. Remove all power:
a. Disconnect each power cord from the power source.
b. Disconnect each power cord from the server.
3. Do one of the following:
• Extend the server from the rack.
• Remove the server from the rack.
4. Remove the access panel.
5. Remove the riser cage.
6. Identify and then remove the PCIe blank from the riser cage.
