LAB-X5000 Series User Guide
Gestures: There are six basic gestures used in navigating the software. 3.3.1.
Tap is used to make selections. 3.3.1.1.
Slide or Drag is used to scroll views and menus. 3.3.1.2.
Long press is used to “pin” and “unpin” elements in Measurements results. 3.3.1.3.
Flick is when you quickly move your finger to jump ahead in a scrolling list. 3.3.1.4.
tap slide up slide down
long press flick left flick right
Main screen: The main screen is divided into three information zones. 3.3.2.
The black bar at the top of the screen contains static information relevant to the 3.3.2.1.
current sample analysis.
The center section contains the most recent analysis results. Flick right or left to 3.3.2.2.
view previous results.
Indicates current operator
level, at top right corner.
Method in use is visible in the
top center.
Time and date of the last
measurement are in the top
left corner.
If visible, Wi-Fi is activated
and connected. In top right
corner.
