1 General information
Applied symbols
SMGB0099 rev.0 - 12/2016
3
1
1.2 Applied symbols
Duringnormalairconditioningsystemdesignworkorunitinstallation,greaterattentionmustbepaidincertainsituations
requiringparticularcareinordertoavoiddamagetotheunit,theinstallationorthebuildingorproperty.
Situationsthatjeopardisethesafetyofthoseinthesurroundingareaorthatputtheunititselfatriskwillbeclearly
indicatedinthismanual.
Toindicatethesesituations,aseriesofspecialsymbolswillbeusedtoclearlyidentifythesesituations.
Paycloseattentiontothesesymbolsandtothemessagesfollowingthem,asyoursafetyandthatofothersdependson
it.
! DANGER
• The text following this symbol contains information and instructions relating directly to your safety and physical wellbeing.
• Not taking these instructions into account could lead to serious, very serious or even fatal injuries to you and others in the
proximities of the unit.
Inthetextsfollowingthedangersymbolyoucanalsondinformationonsafeproceduresduringunitinstallation.
! CAUTION
• The text following this symbol contains information and instructions relating directly to your safety and physical wellbeing.
• Not taking these instructions into account could lead to minor injuries to you and others in the proximities of the unit.
• Not taking these instructions into account could lead to unit damage.
Inthetextsfollowingthecautionsymbolyoucanalsondinformationonsafeproceduresduringunitinstallation.
? NOTE
• The text following this symbol contains information or instructions that may be of use or that require a more thorough explanation.
• Instructions regarding inspections to be made on unit parts or systems may also be included.
