2 Unit installation
RPC - Ceiling
SMGB0099 rev.0 - 12/2016
41
2
2.4 RPC - Ceiling
2.4.1 Accessories supplied with the unit RPC-FSN3
Check that the following accessories are supplied with the unit.
? NOTE
Please contact your HITACHI distributor if any of the accessories has not been supplied with the unit.
Accessory Appearance Quantity Purpose
Suspension bracket 2 For unit suspension.
Washer 8 For suspension bracket
Pipe Insulation (Large) 1
For refrigerant piping connection
Pipe Insulation (Small) 1
Cord Clamp (Large) 6 For Fixing Insulation
Cord Clamp (Small) 1 For Fixing Plug
Drain hose 1
For the drain hose connection.
Wire clamp 2
Insulation material
(5T x 200 x 200mm)
2 For the drain hose connection.
To Next Page
