9 Servicing
RPI-(0.6-6.0)FSN4E - Ducted indoor unit
SMGB0099 rev.0 - 12/2016
290
9.6 RPI-(0.6-6.0)FSN4E - Ducted indoor unit
9.6.1 Removal of the electrical box
RPI-(0.6-1.5)FSN4E RPI-(2.0-6.0)FSN4E
1
1
Nº Part
1 Location of the electrical box cover
RPI-(0.6-1.5)FSN4E RPI-(2.0-6.01)FSN4E
1
1
2
3
4
Nº Part
1 Set screw
2 Terminal board
3 Transformer
4 PCB
