5 Control system
Safety protection and control
SMGB0099 rev.0 - 12/2016
197
5
5.10 Safety protection and control
Setting control and safety devices for indoor units
Model RCI-FSN4 RCIM-FSN4(E)
For the evaporator fan
motor: internal thermostat
Switch off ºC
80 ±4 (*) 100±4 (*)
Switch on ºC
For the control circuit: fuse
capacity
- A 5 5
Freeze Protection
Cut-Out ºC 0
Cut-in ºC 14
Thermostat differential ºC 2
Model RCD RPC-FSN3E RPC-FSN3 RPI(M)
RPI-(8.0/10.0)FSN3E(-f)
RPI-(16.0/20.0)FSN3PE(-f)
RPK RPF(I)
For the evaporator
fan motor: internal
thermostat
Switch off ºC 130±5 100 (*) 100
-10
/
+15
110±10
(**)
140±10
100 (*)
130±5
Switch on ºC 83±15 90±15 95
-10
/
+15
90±10(**) 90±15 93±15
For the control circuit:
fuse capacity
- A 5 5 5 5 5 5 5
? NOTE
(*) Chip Ceramic PTC (Autoreset, non-adjustable)
