3–6 Installing Your Array
Hitachi Simple Modular Storage 100 User’s Guide
WARNING! During installation, if your Hitachi Simple Modular Storage 100
falls at a high position, a personal injury will be caused. Three or more
persons are required to installing the array in a rack above chest level.
Perform the positioning, fastening, or other handlings very carefully.
CAUTION!Be sure to perform the rack installation with three or
more persons. Work carefully because a single Hitachi Simple
Modular Storage 100 can weigh 72.6 pounds (33 kg). Be sure to
install the array from the bottom of the rack to prevent the rack
from falling. Lift the array up to the height suitable for mounting.
Adjust the position of the array, so it is seated in the center of the
rack frame. Shift the array onto the rails in the rack frame. When
shifting the array, push it in to the end gently.
