13.2.2 CC-Link Option
 CC-Link communication dedicated parameters are not provided on the inverter main unit.
For more information on parameters that need to be set, refer to the "WJ-CCL Quick Reference
Guide (NT331*)" (Only in Japanese).
13.2.3 EtherCAT Option
 Parameters dedicated for EtherCAT communication are not provided on the inverter main unit.
For more information on parameters that need to be set, refer to the "WJ-ECT Quick Reference
Guide (NT339*X)".
13.2.4 PROFIBUS Option
 The following table shows the parameters dedicated for PROFIBUS communication.
For more information on the following table and parameters that need to be set, refer to the "WJ-
PB Quick Reference Guide (NT354*X)".
Code
Item
Content
Data
[P160]
to
[P169]
Flexible command writing
register 1 to 10
Set the communication data when
Telegram103 to 105 is selected.
0000h to
FFFFh
[P170]
to
[P179]
Flexible command reading
register 1 to 10
0000h to
FFFFh
[P180]
PROFIBUS Node address
Sets the node address of PROFIBUS.
0 to 125
[P181]
PROFIBUS Clear Mode
selection
Not used.
00 to 01
[P182]
PROFIBUS Map selection
Not used.
00 to 02
13.2.5 PROFINET Option
 The following table shows the parameters dedicated to PROFINET communication.
For more information on the following table and parameters that need to be set, refer to the "WJ-
PN Quick Reference Guide (NT355*X)".
Code
Item
Content
Data
[P160]
to
[P169]
Flexible command writing
register 1 to 10
Set the communication data when
Telegram103 to 105 is selected.
0000h to
FFFFh
[P170]
to
[P179]
Flexible command reading
register 1 to 10
0000h to
FFFFh
