Hitachi WJ Series

Chapter 18 List of Parameters/Modbus Coil/Register Numbers
18-2-3
Code
Name
Data range
Initial
value
Set
value
Change
during
running
Modbus communication
Page
Register No.
Data Range
Resolution
H023
Async. Motor
constant I0, 1st-
motor
0.01 to 655.35 (A)
Depending
on
capacity
×
151Ch
1 to 65535
0.01
8-1-14
9-5-12
H223
Async. Motor
constant I0, 2nd-
motor
×
251Ch
0.01
H024
Async. Motor
constant J, 1st-
motor
0.001 to 9999.000 (kgm
2
)
Depending
on
capacity
×
151Dh (High)
151Eh (Low)
1 to
9999000
0.001
H224
Async. Motor
constant J, 2nd-
motor
251Dh (High)
251Eh (Low)
0.001
H030
Async. Motor
constant R1, 1st-
motor (Auto-
tuning data)
0.001 to 65.535 (Ω)
Depending
on
capacity
×
1525h
1 to 65535
0.001
8-3-1
9-5-12
H230
Async. Motor
constant R1,
2nd-motor (Auto-
tuning data)
Depending
on
capacity
×
2525h
0.001
H031
Async. Motor
constant R2, 1st-
motor (Auto-
tuning data)
0.001 to 65.535 (Ω)
Depending
on
capacity
×
1527h
1 to 65535
0.001
H231
Async. Motor
constant R2,
2nd-motor (Auto-
tuning data)
Depending
on
capacity
×
2527h
0.001
H032
Async. Motor
constant L, 1st-
motor (Auto-
tuning data)
0.01 to 655.35 (mH)
Depending
on
capacity
×
1529h
1 to 65535
0.01
H232
Async. Motor
constant L, 2nd-
motor (Auto-
tuning data)
Depending
on
capacity
×
2529h
0.01
H033
Async. Motor
constant I0, 1st-
motor (Auto-
tuning data)
0.01 to 655.35 (A)
Depending
on
capacity
×
152Bh
1 to 65535
0.01
H233
Async. Motor
constant I0, 2nd-
motor (Auto-
tuning data)
Depending
on
capacity
×
252Bh
0.01
H034
Async. Motor
constant J, 1st-
motor (Auto-
tuning data)
0.001 to 9999.000 (kgm
2
)
Depending
on
capacity
×
152Ch (High)
152Dh (Low)
1 to
9999000
0.001
H234
Async. Motor
constant J, 2nd-
motor (Auto-
tuning data)
Depending
on
capacity
×
252Ch (High)
252Dh (Low)
0.001
H050
Slip
compensation P-
gain at V/f with
encoder
0.00 to 10.00 (times)
0.20
✓
153Dh
0 to 1000
0.01
9-5-8
H051
Slip
compensation I-
gain at V/f with
encoder
0 to 1000 (s)
2
✓
153Eh
0 to 1000
1
H102
to
H134
These parameters are SM/PMM related functions.
Contact your supplier or local Hitachi sales office for details.
-
-
-
-
