Hitachi WJ Series User Manual

Chapter 18 List of Parameters/Modbus Coil/Register Numbers
18-2-5
Code
Name
Data range
Initial
value
Set
value
Change
during
running
Modbus communication
Page
Register No.
Data Range
Resolution
P045
Operation
selection at
option
communication
timeout
00: Trip
01: Trip after deceleration stop
02: Ignore
03: Free run stop
04: Deceleration stop
00
×
162Fh
0 to 4
-
13-2-1
P046
DeviceNet
assembly
instance number
0 to 20
1
×
1630h
0 to 20
1
-
P048
DeviceNet idle
mode action
selection
00: Trip
01: Trip after deceleration stop
02: Ignore
03: Free run
04: Deceleration stop
00
×
1632h
0 to 4
-
-
P049
Number of poles
for rotation
speed
0 (disable),
2/ 4/ 6/ to / 46/ 48 (poles)
0
×
1633h
0 (disable)
1 (2 poles)
2 (4 poles)
3 (6 poles)
to
23 (46 poles)
24 (48 poles)
-
-
P055
Pulse frequency
scale
1.0 to 32.0 (kHz)
25.0/
1.5/
25.0
*2
✓
1639h
10 to 320
0.1
9-2-13
P056
Pulse frequency
filter time
constant
0.01 to 2.00 (s)
0.10
✓
163Ah
1 to 200
0.01
P057
Pulse frequency
bias value
-100 to +100 (%)
0
✓
163Bh
-100 to +100
1
P058
Pulse upper
frequency
detection level
0 to 100 (%)
100
✓
163Ch
0 to 100
1
P059
Pulse lower
frequency
detection level
0.01 to 20.00 (%)
1.00
✓
163Dh
1 to 2000
0.01
P060
Position set-point 0
Position control range
(reverse) [P073] to
Position control range
(forward) [P072] (pls)
* Set by multiplying by 1.
0
✓
163Eh (High)
163Fh (Low)
Position
control range
(reverse)
[P073] to
Position
control range
(forward)
[P072]
1
9-14-2
P061
Position set-point 1
0
✓
1640h (High)
1641h (Low)
1
P062
Position set-point 2
0
✓
1642h (High)
1643h (Low)
1
P063
Position set-point 3
0
✓
1644h (High)
1645h (Low)
1
P064
Position set-point 4
0
✓
1646h (High)
1647h (Low)
1
P065
Position set-point 5
0
✓
1648h (High)
1649h (Low)
1
P066
Position set-point 6
0
✓
164Ah (High)
164Bh (Low)
1
P067
Position set-point 7
0
✓
164Ch (High)
164Dh (Low)
1
P068
Homing mode
selection
00: Low-speed homing
01: High-speed homing
00
✓
164Eh
0 to 1
-
9-14-8
P069
Homing direction
selection
00: Forward
01: Reverse
01
✓
164Fh
0 to 1
-
P070
Low-speed
homing speed
0.00 to 10.00 (Hz)
(100.00 (Hz))
*1
5.00
✓
1650h
0 to 1000
(10000)
*1
0.01
P071
High-speed
homing speed
0.00 to Maximum frequency,
1st-motor (Hz)
5.00
✓
1651h
0 to
Maximum
frequency,
1st-motor
0.01
P072
Position control
range (forward)
0 to +268435455
+268435455
✓
1652h (High)
1653h (Low)
0 to
+268435455
1
9-14-2
P073
Position control
range (reverse)
-268435455 to 0
-268435455
✓
1654h (High)
1655h (Low)
-268435455
to 0
1
*1. When in WJ200 high frequency compatible mode.
*2. The default settings when initialize by setting 00/01/03 to "Initialize data selection [b085]".
