Connections 15
Doc: HMSI-168-92 Rev: 3.00Netbiter EasyConnect Gateway User Manual
2.4.6 USB Connector
TheUSBconnectorcanbeusedtoconnectlocallytotheNetbiterEC310/350forfirmware
upgrades,configurationortroubleshooting.
Seealso“LocalConfiguration”onpage37.
2.4.7 3G/GPRS Antenna Connector (Netbiter EC350 only)
The3G/GPRSantennaconnectoronthefrontoftheunitisastandardfemaleSMAscrew
connector.Astubantennaissuppliedasstandard,andoptionalexternalantennasare
availablefromyoursupplier.
2.4.8 GPS Antenna Connector (Netbiter EC350 only)
TheNetbiterEC350hasabuilt‐inGPSreceiver.AnexternalGPSantenna(notincluded)
shouldbeconnectedtothefemaleSMAscrewconnectorontheundersideoftheunit.The
connectoralsoprovidespowerforactiveGPSantennas.
USB connector
2G/3G antenna connector
GPS antenna connector
