INTRODUCTION
1.14
Imager Duo Operator’s Manual
Server Refer to the documents that come with the
equipment
Fusing:
Imaging Station Two 5 x 20mm, 6.3A time delay glass fuses
Image Processor Controller Refer to the documents that come with the
equipment
Server Refer to the documents that come with the
equipment
Protective Temperature Coefficient Devices
The Imaging Station contains protective temperature coefficient (PTC) devices
intended for protection against occasional overcurrent or overtemperature fault
conditions. These devices automatically reset after the overcurrent or overtem-
perature condition has been removed.
The PTCs locations and functions are as follows:
System Hardware Electromechanical Processor (SHEMP)
F1 - 1A PTC - 5V sensor power to sensor ports J4 and J5
F2 - 1A PTC - 5V sensor power to sensor ports J2 and J3
F3 - 1A PTC - Isolated 5V for the CAN BUS
F4 - 500ma PTC - 24V line to protect against motor or drive failure
Servo Interface Module (SERVIM)
R21 - 1.85A PTC - 24V line to protect FETS and motors
Stepper Interface Module (STEPIM)
R22, R28 1.85A PTC
Digital I/O Module
F1 - 300ma PTC - 12V sensor power to connector J1
F2 - 1A PTC - 5V sensor power to connector J2
Dimensions and Weight (Approximate)
Imaging Station:
22” (55.8 cm) H x 25” (63.5 cm) W x 32.5” (82.5 cm) D
170 lbs (77kg) uncrated
Image Processor Controller, Server and other components: Refer to the docu-
ments that come with the equipment
