TXR_RXR Register
The TXR_RXR register is the data register which is used to store the data to be transmitted on the
TX pin or being received from the RX pin.
Bit 7 6 5 4 3 2 1 0
Name TXRX7 TXRX6 TXRX5 TXRX4 TXRX3 TXRX2 TXRX1 TXRX0
R/W R/W R/W R/W R/W R/W R/W R/W R/W
POR x x x x x x x x
"x": unknown
Bit 7~0 TXRX7~TXRX0: UART Transmit/Receive Data bits
USR Register
The USR register is the status register for the UART, which can be read by the program to
determine the present status of the UART. All ags within the USR register are read only and further
explanations are given below.
Bit 7 6 5 4 3 2 1 0
Name PERR NF FERR OERR RIDLE RXIF TIDLE TXIF
R/W R R R R R R R R
POR 0 0 0 0 1 0 1 1
Bit 7 PERR: Parity error ag
0: No parity error is detected
1: Parity error is detected
The PERR ag is the parity error ag. When this read only ag is "0", it indicates a
parity error has not been detected. When the ag is "1", it indicates that the parity of
the received word is incorrect. This error ag is applicable only if Parity mode (odd or
even) is selected. The ag can also be cleared by a software sequence which involves
a read to the status register USR followed by an access to the RXR data register.
Bit 6 NF: Noise ag
0: No noise is detected
1: Noise is detected
The NF flag is the noise flag. When this read only flag is "0", it indicates no noise
condition. When the ag is "1", it indicates that the UART has detected noise on the
receiver input. The NF ag is set during the same cycle as the RXIF ag but will not
be set in the case of as overrun. The NF ag can be cleared by a software sequence
which will involve a read to the status register USR followed by an access to the RXR
data register.
Bit 5 FERR: Framing error ag
0: No framing error is detected
1: Framing error is detected
The FERR ag is the framing error ag. When this read only ag is "0", it indicates
that there is no framing error. When the ag is "1", it indicates that a framing error
has been detected for the current character. The ag can also be cleared by a software
sequence which will involve a read to the status register USR followed by an access to
the RXR data register.
Bit 4 OERR: Overrun error ag
0: No overrun error is detected
1: Overrun error is detected
The OERR ag is the overrun error ag which indicates when the receiver buffer has
overowed. When this read only ag is "0", it indicates that there is no overrun error.
When the ag is "1", it indicates that an overrun error occurs which will inhibit further
transfers to the RXR receive data register. The ag is cleared by a software sequence,
which is a read to the status register USR followed by an access to the RXR data
register.
