BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Register
BS66F340 BS66F350 BS66F360 BS66F370
Reset
(Power On)
LVR Reset
(Normal
Operation)
WDT Time-out
(Normal
Operation)
WDT Time-out
(IDLE or SLEEP)*
PCPU ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PD ● ● ● 1111 1111 1111 1111 1111 1111 uuuu uuuu
PDC ● ● ● 1111 1111 1111 1111 1111 1111 uuuu uuuu
PDPU ● ● ● 0000 0000 0000 0000 0000 0000 0uuuu uuuu
MFI0 ● ● ● ● --00 --00 --00 --00 --00 --00 --uu --uu
MFI1 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
MFI2 ● ● ● ● -000 -000 -000 -000 -000 -000 -uuu -uuu
MFI3 ● ● ● ● --00 --00 --00 --00 --00 --00 --uu --uu
ADRL
(ADRFS=0)
● ● ● ● xxxx ---- xxxx ---- xxxx ---- uuuu ----
ADRL
(ADRFS=1)
● ● ● ● xxxx xxxx uuuu uuuu uuuu uuuu uuuu uuuu
ADRH
(ADRFS=0)
● ● ● ● xxxx xxxx uuuu uuuu uuuu uuuu uuuu uuuu
ADRH
(ADRFS=1)
● ● ● ● ---- xxxx ---- uuuu ---- uuuu ---- uuuu
ADCR0 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
ADCR1 ● ● ● ● 0-00 -000 0-00 -000 0-00 -000 u-uu -uuu
PSCR0 ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
TB0C ● ● ● ● 0--- -000 0--- -000 0--- -000 u--- -uuu
TB1C ● ● ● ● 0--- -000 0--- -000 0--- -000 u--- -uuu
SIMTOC ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
SIMC0 ● ● ● ● 111- 0000 111- 0000 111- 0000 uuu- uuuu
SIMC1 ● ● ● ● 1000 0001 1000 0001 1000 0001 uuuu uuuu
SIMD ● ● ● ● xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
SIMA/
SIMC2
● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM0C0 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM0C1 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM0DL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM0DH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
CTM0AL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM0AH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
EEA ● ● ● ● -000 0000 -000 0000 -000 0000 -uuu uuuu
EED ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PSCR1 ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
SLEDC ● --00 0000 --00 0000 --00 0000 --uu uuuu
SLEDC ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
SLEDC1 ● ---- 0000 ---- 0000 ---- 0000 ---- uuuu
PTMC0 ● ● ● ● 0000 0--- 0000 0--- 0000 0--- uuuu u---
PTMC1 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PTMDL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PTMDH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
PTMAL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PTMAH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
PTMRPL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PTMRPH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
FC0 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
