Rev. 1.60 88 August 20, 2019 Rev. 1.60 89 August 20, 2019
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Register
BS66F340 BS66F350 BS66F360 BS66F370
Reset
(Power On)
LVR Reset
(Normal
Operation)
WDT Time-out
(Normal
Operation)
WDT Time-out
(IDLE or SLEEP)*
FC1 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
FC2 ● ● ● ---- ---0 ---- ---0 ---- ---0 ---- ---u
FARL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
FARH ● ---- 0000 ---- 0000 ---- 0000 ---- uuuu
FARH ● ---0 0000 ---0 0000 ---0 0000 ---u uuuu
FARH ● --00 0000 --00 0000 --00 0000 --uu uuuu
FARH ● -000 0000 -000 0000 -000 0000 -uuu uuuu
FD0L ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
FD0H ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
FD1L ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
FD1H ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
FD2L ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
FD2H ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
FD3L ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
FD3H ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
STMC0 ● ● ● ● 0000 0--- 0000 0--- 0000 0--- uuuu u---
STMC1 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
STMDL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
STMDH ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
STMAL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
STMAH ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
STMRP ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM1C0 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM1C1 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM1DL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM1DH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
CTM1AL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
CTM1AH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
TSC0 ● ● ● ● 010- ---- 010- ---- 010- ---- uuu- ----
TSC1 ● ● ● ● 000- ---- 000- ---- 000- ---- uuu- ----
TSC2 ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TSC3 ● ● ● ● --0- ---- --0- ---- --0- ---- --u- ----
PE ● --11 1111 --11 1111 --11 1111 --uu uuuu
PE ● ● ● 1111 1111 1111 1111 1111 1111 uuuu uuuu
PEC ● --11 1111 --11 1111 --11 1111 --uu uuuu
PEC ● ● ● 1111 1111 1111 1111 1111 1111 uuuu uuuu
PEPU ● --00 0000 --00 0000 --00 0000 --uu uuuu
PEPU ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PF ● ● --11 1111 --11 1111 --11 1111 --uu uuuu
PFC ● ● --11 1111 --11 1111 --11 1111 --uu uuuu
PFPU ● ● --00 0000 --00 0000 --00 0000 --uu uuuu
USR ● ● ● ● 0000 1011 0000 1011 0000 1011 uuuu uuuu
UCR1 ● ● ● ● 0000 00x0 0000 00x0 0000 00x0 uuuu uuuu
UCR2 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TXR_RXR ● ● ● ● xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
BRG ● ● ● ● xxxx xxxx xxxx xxxx xxxx xxxx uuuu uuuu
PG ● 1111 1111 1111 1111 1111 1111 uuuu uuuu
