BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Register
BS66F340 BS66F350 BS66F360 BS66F370
Reset
(Power On)
LVR Reset
(Normal
Operation)
WDT Time-out
(Normal
Operation)
WDT Time-out
(IDLE or SLEEP)*
PGC ● 1111 1111 1111 1111 1111 1111 uuuu uuuu
PGPU ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKTMR ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKC0 ● ● ● ● 0000 0-00 0000 0-00 0000 0-00 uuuu u-uu
TK16DL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TK16DH ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKC1 ● ● ● ● 0000 0011 0000 0011 0000 0011 uuuu uuuu
TKM016DL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM016DH ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM0ROL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM0ROH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
TKM0C0 ● ● ● ● --00 0000 --00 0000 --00 0000 --uu uuuu
TKM0C1 ● ● ● ● 0-00 0000 0-00 0000 0-00 0000 u-uu uuuu
TKM0C2 ● ● ● ● 1110 0100 1110 0100 1110 0100 uuuu uuuu
TKM116DL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM116DH ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM1ROL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM1ROH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
TKM1C0 ● ● ● ● --00 0000 --00 0000 --00 0000 --uu uuuu
TKM1C1 ● ● ● ● 0-00 0000 0-00 0000 0-00 0000 u-uu uuuu
TKM1C2 ● ● ● ● 1110 0100 1110 0100 1110 0100 uuuu uuuu
TKM216DL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM216DH ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM2ROL ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM2ROH ● ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
TKM2C0 ● ● ● ● --00 0000 --00 0000 --00 0000 --uu uuuu
TKM2C1 ● ● ● ● 0-00 0000 0-00 0000 0-00 0000 u-uu uuuu
TKM2C2 ● ● ● ● 1110 0100 1110 0100 1110 0100 uuuu uuuu
TKM316DL ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM316DH ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM3ROL ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM3ROH ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
TKM3C0 ● ● ● --00 0000 --00 0000 --00 0000 --uu uuuu
TKM3C1 ● ● ● 0-00 0000 0-00 0000 0-00 0000 u-uu uuuu
TKM3C2 ● ● ● 1110 0100 1110 0100 1110 0100 uuuu uuuu
TKM416DL ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM416DH ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM4ROL ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM4ROH ● ● ● ---- --00 ---- --00 ---- --00 ---- --uu
TKM4C0 ● ● ● --00 0000 --00 0000 --00 0000 --uu uuuu
TKM4C1 ● ● ● 0-00 0000 0-00 0000 0-00 0000 u-uu uuuu
TKM4C2 ● ● ● 1110 0100 1110 0100 1110 0100 uuuu uuuu
TKM516DL ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM516DH ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM5ROL ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM5ROH ● ● ---- --00 ---- --00 ---- --00 ---- --uu
TKM5C0 ● ● --00 0000 --00 0000 --00 0000 --uu uuuu
