BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
BS66F340/BS66F350/BS66F360/BS66F370
Touch A/D Flash MCU with LED Driver
Register
BS66F340 BS66F350 BS66F360 BS66F370
Reset
(Power On)
LVR Reset
(Normal
Operation)
WDT Time-out
(Normal
Operation)
WDT Time-out
(IDLE or SLEEP)*
TKM5C1 ● ● 0-00 0000 0-00 0000 0-00 0000 u-uu uuuu
TKM5C2 ● ● 1110 0100 1110 0100 1110 0100 uuuu uuuu
TKM616DL ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM616DH ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM6ROL ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM6ROH ● ● ---- --00 ---- --00 ---- --00 ---- --uu
TKM6C0 ● ● --00 0000 --00 0000 --00 0000 --uu uuuu
TKM6C1 ● ● 0-00 0000 0-00 0000 0-00 0000 u-uu uuuu
TKM6C2 ● ● 1110 0100 1110 0100 1110 0100 uuuu uuuu
TKM716DL ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM716DH ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM7ROL ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM7ROH ● ---- --00 ---- --00 ---- --00 ---- --uu
TKM7C0 ● --00 0000 --00 0000 --00 0000 --uu uuuu
TKM7C1 ● 0-00 0000 0-00 0000 0-00 0000 u-uu uuuu
TKM7C2 ● 1110 0100 1110 0100 1110 0100 uuuu uuuu
EEC ● ● ● ● ---- 0000 ---- 0000 ---- 0000 ---- uuuu
IFS ● ● ● ● --00 0000 --00 0000 --00 0000 --uu uuuu
PAS0 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PAS1 ● 00-- 0000 00-- 0000 00-- 0000 uu-- uuuu
PAS1 ● ● ● ---- 0000 ---- 0000 ---- 0000 ---- uuuu
PBS0 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PBS1 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PCS0 ● ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PCS1 ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PDS0 ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PDS1 ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PES0 ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PES0 ● 0000 ---- 0000 ---- 0000 ---- uuuu ----
PES1 ● ---- 0000 ---- 0000 ---- 0000 ---- uuuu
PES1 ● ● ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PFS0 ● ● ---- 0000 ---- 0000 ---- 0000 ---- uuuu
PGS0 ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PGS1 ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
PH ● --11 1111 --11 1111 --11 1111 --uu uuuu
PHC ● --11 1111 --11 1111 --11 1111 --uu uuuu
PHPU ● --00 0000 --00 0000 --00 0000 --uu uuuu
TKM816DL ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM816DH ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM8ROL ● 0000 0000 0000 0000 0000 0000 uuuu uuuu
TKM8ROH ● ---- --00 ---- --00 ---- --00 ---- --uu
TKM8C0 ● --00 0000 --00 0000 --00 0000 --uu uuuu
TKM8C1 ● 0-00 0000 0-00 0000 0-00 0000 u-uu uuuu
TKM8C2 ● 1110 0100 1110 0100 1110 0100 uuuu uuuu
Note: "u" stands for unchanged
"x" stands for "unknown"
"-" stands for unimplemented
